| Overview | |
|---|---|
| Dimensions | 212.9 x 99.4 x 33.5 mm (8.4 x 3.9 x 1.3") |
| Port Layout | |
| 2.5 GbE RJ45 | 8 (All PoE++) (2.5G/1G/100M/10M) |
| 10 GbE RJ45 | 1 (PoE+++) (10G/5G/2.5G/1G/100M) |
| 10G SFP+ | 1 |
| Max. PoE Output | Up to PoE++ |
| Total PoE Availability | PoE+++ input: 76W PoE++ input: 46W PoE+ input: 16W 210W AC adapter input: 196W |
| Form Factor | Compact Desktop, wall, DIN, magnetic |
| Performance | |
|---|---|
| Switching Capacity | 60 Gbps |
| Total Non-Blocking Throughput | 30 Gbps |
| Forwarding Rate | 45 Mpps |
| Supported VLANs | 256 |
| MAC Address Table Size | 4,000 |
| Layer 2 Features | |
|---|---|
| DHCP Snooping & Guarding | Yes |
| Egress Rate Limit | Yes |
| Flow Control | Yes |
| Storm Control | Yes |
| Multicast & Broadcast Rate Limiting | Yes |
| Port Isolation | Yes |
| Port Mirroring | Yes |
| Jumbo Frames | Yes |
| Loop Protection | Yes |
| Hardware | |
|---|---|
| PoE Ports | PoE++: 8 |
| Max. PoE Wattage per Port by PSE | PoE: 15.4W | PoE+: 32W | PoE++: 64W |
| Max. Power Consumption | 14W (Excluding PoE output) with PoE input 17W (Excluding PoE output) with AC adapter input 210W (Including PoE Output) |
| Power Method | (1) AC/DC adapter (Excluded) (1) PoE+++ |
| Power Input Method | DC Input PoE |
| Supported Voltage Range | 50—57V DC/PoE |
| Management | Ethernet |
| Weight | 567 g (20 oz) |
| Enclosure Material | Polycarbonate |
| Mount Material | Polycarbonate |
| Ambient Operating Temperature | -20 to 45° C (-4 to 113° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC |
| Software | |
|---|---|
| Application Requirements | UniFi Network --> Version 9.0.114 and later |
