Overview | |
---|---|
Dimensions | 442 x 120 x 43.7 mm (17.4 x 4.7 x 1.7") |
Port Layout | 10G SFP+ : 8 |
Form Factor | Rack mount (1U) |
Performance | |
---|---|
Switching Capacity | 160 Gbps |
Total Non-Blocking Throughput | 80 Gbps |
Forwarding Rate | 119 Mpps |
Supported VLANs | 1,000 |
MAC Address Table Size | 16,000 |
Packet Buffer Size | 1.5 MB |
Layer 2 Features | |
---|---|
LACP Port Aggregation | Yes |
STP & RSTP | Yes |
QoS (DSCP) | Yes |
Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron) | Yes |
Advanced IGMP Configuration (Querier, Fast Leave, Router Port) | Yes |
IGMP Snooping | Yes |
802.1X Control | Yes |
MAC-Based ACLs & Device Isolation | Yes |
DHCP Snooping & Guarding | Yes |
Egress Rate Limit | Yes |
Flow Control | Yes |
Storm Control | Yes |
Multicast & Broadcast Rate Limiting | Yes |
MAC Address Blocking | Yes |
IP-Based ACLs & Network Isolation | Yes |
MAC-Based Port Restriction | Yes |
Port Isolation | Yes |
Port Mirroring | Yes |
Jumbo Frames | Yes |
LLDP-MED | Yes |
Voice VLAN | Yes |
Loop Protection | Yes |
Hardware | |
---|---|
Max. Power Consumption | 36W (Including SFP modules) |
Power Method | Universal input, 100—240V AC, 50/60 Hz |
Power Input Method | AC input |
Power Supply | AC/DC, internal, 36W |
Supported Voltage Range | 100—240V AC |
Management | Ethernet AR |
Heat Dissipation (Excluding PoE Output) | 102.36 BTU/hr |
Weight | Without mounting brackets: 2.6 kg (5.8 lb) With mounting brackets: 2.7 kg (6 lb) |
Enclosure Material | SGCC steel |
Mount Material | SGCC steel |
Supported Rack Depth | 400~1200 mm (15.7-47.2") |
LCM Display | 1.3" touchscreen |
ESD/EMP Protection | Air: ± 16kV, contact: ± 12kV |
Ambient Operating Temperature | -5 to 40° C (23 to 104° F) |
Ambient Operating Humidity | 10 to 90% noncondensing |
Certifications | CE, FCC, IC |
NDAA Compliant | Yes |
Software | |
---|---|
Application Requirements | UniFi Network - Version 5.14.12 and later |
